x| NUP2306ET |
| d | 30 | mm | Bore diameter |
| D | 72 | mm | Outside diameter |
| B | 27 | mm | Width |
| FW | 40.5 | mm | Raceway diameter of inner ring |
| r (min.) | 1.1 | mm | Chamfer dimension |
| r1 (min.) | 1.1 | mm | Chamfer dimension |
| Cr | 92000 | N | Basic dynamic load rating |
| C0r | 77500 | N | Basic static load rating |
| Thermal Speed Rating (Oil-bath) | 9500 | min-1 | Oil-bath lubrication subject to conditions outlined in ISO 15312 |
| Mechanical (forced-circulation oil) | 13000 | min-1 | Properly designed and controlled forced-circulation oil lubrication |
| Grease | 8000 | min-1 | Grease lubrication |
| Oil (Oil-bath) | 9500 | min-1 | Oil-bath lubrication |
| da (min.) | 36.5 | mm | Diameter of shaft abutment (min) |
| db (min.) | 36.5 | mm | Diameter of shaft / spacer sleeve abutment |
| db (max.) | 39 | mm | Diameter of shaft / spacer sleeve abutment |
| dc (min.) | 44 | mm | Diameter of shaft abutment |
| dd (min.) | 48 | mm | Diameter of shaft abutment |
| Da (max.) | 65.5 | mm | Diameter of housing abutment |
| rb (max.) | 1 | mm | Radius of shaft or housing fillet |
| ra (max.) | 1 | mm | Radius of shaft or housing fillet |
| Mass approx. | 0.543 | kg | Mass approx. |
