Description
x| Manufacturer | InWin |
| Part Number | IW-RS424-02M-CR1K2.H |
| Motherboard Support | ATX (12" x 9.6") ATX (12" x 10") SSI EEB (12" x 13") |
| Drive Support | 24 x 3.5"/2.5" Hotswap Drive Bays 2 x 2.5" Internal Drive Bays 2 x 2.5" Rear Drive Bays (Optional) |
| Backplane | 12Gb/s Mini-SAS HD Backplane Supports SAS 3.0 and SATA3 Drives |
| Fan Support | 3 x 120x38mm PWM Easy Swap Fans 2 x 80mm Rear Fan (Optional) |
| Expansion Slots | 7 x PCI Slots (Full Height) |
| Front Panel | 1 x Power Switch 1 x ID Switch 1 x System Reset 1 x NMI 2 x USB 3.0 6 x Status LED (Power, HDD, LAN, System Fail) |
| Power Supply | 1200W 1+1 80+ Platinum CRPS Redundant Power Supply |
| Case Dimensions | 625 x 482.6 x 177mm 24" x 19" x 7" Net Weight: 38.45 lbs Gross Weight: 48.96 lbs |
| Mounting | Supports 28" Ball Bearing Slide Rail |
| Warranty | 1-Year Manufacturer's Limited Warranty |
