Beckhoff EL3104

Beckhoff EL3104

Overview

The Beckhoff EL3104 is a 4-channel analog input terminal designed for precise voltage measurement in automation systems. Supporting ±10 V input range and 12-bit resolution, it ensures accurate data acquisition for control and monitoring applications. Its EtherCAT interface enables high-speed, deterministic communication with controllers, making it ideal for real-time systems.

Key Features

• 4 analog input channels

• ±10 V voltage measurement range

• 12-bit resolution for accurate signal capture

• High-speed EtherCAT communication

• Compact 12 mm housing for space-saving installations

• Galvanic isolation between channels and system bus

Technical Specifications

• Part Number: EL3104

• Manufacturer: Beckhoff

• Channels: 4

• Input Voltage Range: ±10 V

• Resolution: 12-bit

• Interface: EtherCAT

• Housing Width: 12 mm

• Operating Temperature: –25 °C to +60 °C

• Mounting: DIN-rail terminal

Applications

• Industrial process monitoring

• Data acquisition systems

• Laboratory instrumentation

• Machine automation

• Sensor signal interfacing

Why Choose the EL3104

• Reliable and precise voltage measurement

• Compact design for optimized panel space

• Seamless integration with EtherCAT I/O systems

• Cost-effective solution for multi-channel applications

Order Now

The Beckhoff EL3104 4-channel analog input terminal is available and ships worldwide.
